CEM DT-372H AC Autoranging Clamp Meters (400AAC)

Voltage DC (Max Range; Basic Accuracy): 600V; ±(0.5%+1d)

Voltage AC (Max Range; Basic Accuracy): 600V; ±(1.5%+2d)

Current AC (Max Range; Basic Accuracy): 400A; ±(2.5%+4d)

Resistance (Max Range; Basic Accuracy): 40MΩ; ±(3.0%+5d)

Temperature (Max Range; Basic Accuracy): 1000°C/1832°F; ±(3.0%+3d)

Capacitance (Max Range; Basic Accuracy): 4000μF; ±(2.5%+5d)

Frequency (Max Range; Basic Accuracy): 10kHz; ±(1.2%+2d)

Continuity check: Buzzer sounds at 50Ω

Diode test: Test current 0.3mA

Jaw opening: 1.2” (30mm)

Size (HxWxD): 197mm x 70mm x 40mm

Weight: 183g

Accessories: Test leads, gift box with carrying case, temperature probe, 1.5Vx2 “AAA” batteries.
