CEM DT-3392 AC/DC Clamp Meters (AC/DC-1000A/600V True RMS)
Function: Max Range - Basic Accuracy - Max. Resolution
AC Current: 1000 A ; ±(2.5%+5d) ; 10mA
DC Current: 1000 A ; ±(3.0%+4d) ; 10mA
AC Voltage: 600V ; ±(0.8%+2d) ; 0.1mV
DC Voltage: 600V ; ±(1.0%+4d) ; 0.1mV
Resistance: 40MΩ ; ±(1.0%+4d) ; 0.1Ω
Capacitance: 40mF ; ±(3.0%+5d) ; 0.01nF
Frequency: 4kHz ; ±(1.2%+3d) ; 0.01MHz
Temperature: 1000ºC/1832ºF ; ±(3.0%+5d) ; 1ºC/ºF
Size (H x W x D): 271mm x 100mm x 47mm
Weight: 508g
Accessories: Test leads, gift box with carrying case, 9V battery and Temperature probe (3391/3391W/3392/3392W/3392BT/3395/3397)
Datasheet
Features | DT-3390 | DT-3391 | DT-3392 | DT-3395 |
True RMS measurements | * | * | * | |
Digital display counts | 4000 | 4000 | 4000 | 6000 |
Electronic overload protection | * | * | * | * |
Analog Bargraph/segments | */41 | */61 | ||
Continuity buzzer & Diode check | * | * | * | * |
Data Hold function | * | * | * | * |
Peak Hold function | * | Min./Max. | ||
Inrush current measurement | ||||
DCA Zero function | * | * | ||
Auto Power Off | * | * | * | * |
Low battery indication | * | * | * | * |
AC/DC Current | AC | AC | * | * |
2” (52mm) Clamp jaw opening | * | * | * | * |
NCV Detection | * | * | * | * |
Function | Max Range | Basic Accuracy | Max. Resolution | DT-3390 | DT-3391 | DT-3392 | DT-3395 |
AC Current | 1000 A | ±(2.5%+5d) | 10mA | * | * | * | * |
DC Current | 1000 A | ±(3.0%+4d) | 10mA | * | * | ||
AC Voltage | 600V | ±(0.8%+2d) | 0.1mV | * | * | * | * |
DC Voltage | 600V | ±(1.0%+4d) | 0.1mV | * | * | * | * |
Resistance | 40MΩ | ±(1.0%+4d) | 0.1Ω | * | * | * | * |
Capacitance | 40mF | ±(3.0%+5d) | 0.01nF | 100µF | 100µF | * | 4000µF |
Frequency | 10MHz | ±(1.2%+3d) | 0.01MHz | * | * | 4kHz | * |
Temperature | 1000ºC/1832ºF | ±(3.0%+5d) | 1ºC/ºF | * | * | * |
