Shaking motion: Switchable Reciprocal/Orbital shaking
Temperature range: +4℃ to +80℃
Temp. control accuracy (*1): ±0.3℃ to ±1.0℃
Speed range (*2): 25 to 300 r/min (200 r/min at the upper of stacked units)
Shaking width: Switchable 25/50 mm (Default: 25 mm)
Platform size/Capacity: 700 × 500 mm (Max. inside height: 385 mm), Erlenmeyer flask 500 mL × 24, 5 L × 4
Door type: Swing lift-up door
Maximum load: approx. 10 kg (Platform not included)
Ambient temp. range (*1): +5℃ to +35℃
Heating/Cooling method: Heater 700 W/Compressor 125 W
Program functions: 1 pattern, 9 segments (4 combinations can be saved): Temp., Shaking speed and Time/per segment (Setting range: 00 h 00 min to 99 h 59 min),Wait function (*3)
Display (Temp. and speed): Digital display
Programming Function: 4 pattern, 9 segment / temperature shaking speed time (for each segment) [time setting range: 00h00min - 99h59min], wait function (*3)
Safety devices/functions: Leakage/Overcurrent breaker, Compressor overheating cut-off circuit, Alarm of abnormal sample temp. (Set as desired), Overload/Overvoltage protection, Fuse, Current limiter, Detecting the door opening and closing,Self-diagnosis function for temperature sensor error, Nonvolatile memory error, Breaking device when motor runaway, Self-check/lamp of filter
Dimensions (W × D × H)/Weight: 1200 (*4) × 800 × 810 mm (Including Top board: 1200 × 750 × 25 mm), Approx. 235 kg
Power supply: AC100V/AC220-240V/12A built-in down transformer
Standard accessories: Universal shaking platform MT-7050 ×1 pc (*5), 2 types Spacer × 2 pcs, Fixing bracket for stackable (*6)
(*1)The temp. of defrost function is not included. Also, the specifications may not be met outside of the ambient temperature range.
(*2)There is a limitation depending on the volume of vessels and the shaking width.
(*3)Shaking will start when reaching the preset temp. (*4)Approximately 1800 mm when a delivery cart (not included) is installed.
(*5)Clamps are not included.
(*6)Included when stacking is desired.
●Temp. range and Temp. stability may not be able to meet the specs when it is frozen by continuous operation. Required to defrost it regularly.
●Due to the large size and weight of this product, transportation and installation costs will be charged separately.
