Karg KT053 Cooling Chambers (+4 ~ 100°C, 0.4kW)

 Performance Data Temperature

Temperature range [°C]: +4...100

Temperature variation at 37 °C [± K]: 0.3

Temperature fluctuation at 37 °C [± K]: 0.1

Recovery time after 30 seconds door open at 37 °C [min]: 2

Electrical data

Rated Voltage [V]: 200…240

Power frequency [Hz]: 50/60

Nominal power [kW]: 0.4

Unit fuse [A]: 10

Phase (Nominal voltage) [ph]: 1~

Outer dimensions

Width net [mm]: 660

Height net [mm]: 635

Depth net [mm]: 630

Wall clearance back [mm]: 100

Wall clearance sidewise [mm]: 240

Doors

Inner doors: 1

Unit doors: 1

Internal Dimensions

Width [mm]: 400

Height [mm]: 400

Depth [mm]: 334

Further Dimension

Interior volume [L]: 53

Net weight of the unit (empty) [kg]: 63

permitted load [kg]: 40

Load per rack [kg]: 15

Environment-specific data

Energy consumption at 25 °C [Wh/h]: 75

Energy consumption at 37 °C [Wh/h]: 75

Sound-pressure level [dB(A)]: 48

Fixtures

Number of shelves (std./max.): 2 / 5
