Measuring range: 50 ~ 1400 kpa
Accuracy:≤± 0.5%
Resolution: 0.01 kpa
Deformation error:≤ 1 mm
Concentricity of upper and lower plates: ≤0.25mm
Pressure: 9mm [(30 ±5)kpa]
Oil delivery speed: 95± 5ml/min
Pressure plate diameter: upper plate diameter [30.5± 0.1mm] lower plate diameter [33.1 ±0.1mm]
Man-machine interface: 3.4 in 320*240 lattice lcd display, real-time display of data changes
Clamping force: 400kpa~1200kpa (adjustable)
Unit conversion: kg/cm2, kpa, lbf /in2
Print out: modular integrated thermal printer
Dimensions: 400-350*500mm
Weight: 42 kg
Working conditions: temperature (20 plus or minus 10 ℃, humidity is < 85%
