Lisun LS2090 LED Power Driver Tester (AC300 V, 2.7A/ DC500V, 8A)
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
1. Input Characteristics Test (AC)
• Measures the input voltage, current, power, power factor, power grid frequency
• The fundamental frequency scope of the current and voltage: 45Hz~65Hz; Narrowband range: 45Hz~5kHz; Broadband range: 45Hz~1MHz.
• Voltage range: 3~300 V (CF=1.67); Current range: 5mA ~ 2.7A (CF=3); Power range: 0.015~800W; Power factor range: 0.000~1.000.2. Input Characteristics Test (DC)
• Measures voltage, current, power.
• Voltage range: 3~500V; Current range: 5mA~8A; Power range: 0.015~4000W3. Output Characteristics Test (AC)
• Measures lamp voltage, lamp current, lamp power.
• Lamp voltage range: 3~300V (CF=3); Lamp current range: 5mA~2.7A(CF=3); Lamp power range: 0.015~800W4. Output Characteristics Test (DC)
• Measures output lamp voltage, lamp current, lamp power, ripple wave current.
• Voltage range: 3~500V; Current range: 5mA~8A; Power range: 0.015~4KW; Ripple wave current range: 5mA~2.5A.5. Output Start Characteristics Test (DC)
• Changing curve and data of the lamp voltage and lamp current within 0~2 seconds.
• Lamp voltage range: 3~500V; Lamp current range: 5mA~8A6. Harmonic Testing
Total harmonic and the harmonic component of 0~50 times, wave ratio, initial phase angle, peak phase angle and the phase Angle.7. Displacement Factor (DF) Testing
The LS2090 is an update version for WT2080, the LS2090 has the Displacement Factor (DF) Testing function.
