Digital I/O connector type: 6-pole jackable screw terminal
Digital Inputs: 2 opto-isolated, 10–30 VDC
Digital Output Purpose: Output to ext. device (programmatically set)
Digital Outputs: 2 opto-isolated, 10–30 VDC, max 100 mA
EMC: EN 61000-6-2:2001 (Immunity), EN 61000-6-3:2001 (Emission), FCC 47 CFR Part 15 Class B (Emission)
f-number: 1.0
Image Frequency: 50 Hz (100/200 Hz with windowing)
Thermal Sensitivity/NETD: < 0.05°C @ +30°C (86°F) / 50 mK
Accuracy: ±2°C or ±2% of reading
Communication & Data Storage
Digital I/O connector type: 6-pole jackable screw terminal
Digital I/O isolation voltage: 500 VRMS
Digital I/O supply voltage: 12/24 VDC, max 200 mA
Digital input purpose: Image tag (start, stop, general), Image flow ctrl. (Stream on/off), Input ext. device (programmatically read)
Digital Inputs: 2 opto-isolated, 10–30 VDC
Digital Output Purpose: Output to ext. device (programmatically set)
Digital Outputs: 2 opto-isolated, 10–30 VDC, max 100 mA
Ethernet: Control and image
Ethernet Communication: TCP/IP socket-based FLIR proprietary and GenICam protocol
Ethernet Connector Type: RJ-45
Ethernet Image Streaming: 16-bit 640 × 480 pixels at 50 Hz, 16-bit 640 × 240 pixels at 100 Hz, 16-bit 640 × 120 pixels at 200 Hz (Signal linear, Temperature linear, Radiometric GigE Vision and GenICam compatible)
Ethernet Protocols: TCP, UDP, SNTP, RTSP, RTP, HTTP, ICMP, IGMP, ftp, SMTP, SMB (CIFS), DHCP, MDNS (Bonjour), uPnP
Ethernet Standard: IEEE 802.3
Ethernet Type: Gigabit Ethernet
USB: Control and image
USB - Communication: TCP/IP socket-based FLIR proprietary
USB - Connector Type: USB Mini-B
USB - Image Streaming: 16-bit 640 × 480
USB - Protocols: TCP, UDP, SNTP, RTSP, RTP, HTTP, ICMP, IGMP, ftp, SMTP, SMB (CIFS), DHCP, MDNS (Bonjour), uPnP
USB - Standard: USB 2 HS
Imaging & Optical
Camera size excl lens (L x W x H): 203 × 73 × 75 mm (8.0 × 2.9 × 3.0 in.)
Detector Pitch: 17 µm
Detector Time Constant: Typical 8 ms
Field of view (FOV): 25° × 19° (31° diagonal)
FLIR Screen-EST Mode: No
f-number: 1.0
Focal Length: 24.6 mm (0.97 in.)
Focus: Automatic or manual (built in motor)
Image Frequency: 50 Hz (100/200 Hz with windowing)
IR Resolution: 640 × 480 pixels
Lens Identification: Automatic
Minimum Focus Distance: 0.25 m (0.82 ft.)
Spatial resolution (IFOV): 0.68 mrad
Thermal Sensitivity/NETD: < 0.05°C @ +30°C (86°F) / 50 mK
Measurement & Analysis
Accuracy: ±2°C or ±2% of reading
Atmospheric transmission correction: Automatic, based on inputs for distance, atmospheric temperature and relative humidity
Camera size (L x W x H): 216 × 73 × 75 mm (8.7 × 2.9 × 3.0 in.)
Emissivity Correction: Variable from 0.01 to 1.0
External Optics & Windows Correction: Automatic, based on input of optics/window transmission and temperature
Measurement Correction: Global object parameters
Object Temperature Range: -20 to +150°C +100 to +650°C +300 to +2000°C
Optics Transmission Correction: Automatic, based on signals from internal sensors
Reflected apparent temperature correction: Automatic, based on input of reflected temperature
General
Contents: Hard transport case or cardboard box, Thermal imaging camera with lens, Utility CD-ROM, Calibration certificate, Ethernet™ cable, USB cable (FLIR A615), Mains cable, Power cable (pig-tailed), Power supply, Printed Getting Started Guide, Printed Important Information Guide, User documentation CD-ROM, Warranty extension card or Registration card, 6-pole screw terminal (mounted on camera)
Housing material: Aluminium
Packaging Size: 360 x 180 x 550 mm (14.2 x 7.1 x 21.7 in.)
Environmental & Certifications
EMC: EN 61000-6-2:2001 (Immunity), EN 61000-6-3:2001 (Emission), FCC 47 CFR Part 15 Class B (Emission)
Encapsulation: IP 30 (IEC 60529)
Humidity (Operating and Storage): IEC 60068-2-30/24 h 95% relative humidity +25°C to +40°C (77 to 104°F)
Operating Temperature Range: –15°C to +50°C (+5°F to +122°F)
Shock: 25 g (IEC 60068-2-27)
Storage Temperature Range: –40°C to +70°C (-40 to 158°F)
Vibration: 2 g (IEC 60068-2-6)
Power
External Power Connector Type: 2-pole jackable screw terminal
External Power Operation: 12/24 VDC, 24 W absolute max
Voltage Allowed range: 10–30 VDC
