IR Resolution : 320 × 240 pixels
Display: 4 in. LCD, 320 × 240 pixels, backlit
Object Temperature Range: –20°C to 150°C (–4°F to 302°F) 0°C to 650°C (32°F to 1202°F)
Image Modes: IR image TI Basic fire-fighting mode Black-and-white fire-fighting mode Fire mode Search-and-rescue mode Heat detection mode Thumbnail gallery
Camera weight incl battery: 1.1 ±0.05 kg (2.4 ±0.1 lb.)
Camera size (L x W x H): 120 x 125 x 280 mm (4.7 x 4.9 x 11 in.)
Imaging & Optical
Contrast optimization: Digital image enhancement using FSX
Depth of Field: 0.84 m to infinity (33 in. to infinity)
Detector Type: Focal plane array (FPA), uncooled microbolometer (VOx)
Field of view (FOV): 51° × 38°
f-number: 1.25
Focal Length: 9 mm (0.35 in.)
Focus: Fixed
Image Frequency: 60 Hz
Image Modes: IR image TI Basic fire-fighting mode Black-and-white fire-fighting mode Fire mode Search-and-rescue mode Heat detection mode Thumbnail gallery
IR Resolution: 320 × 240 pixels
Non-radiometric IR video recording: MPEG-4 to internal flash memory
Non-radiometric IR video streaming: Uncompressed colorized video using USB
Pitch: 25 µm
Spatial resolution (IFOV): 2.8 mrad
Spectral Range: 7.5-13 µm
Storage Capacity: 200 files in total, with a maximum duration of 30 minutes. The total number of files is co-dependent on the number of saved images.
Thermal Sensitivity/NETD: <30 mK @ 30°C (86°F)
Zoom: 2× digital zoom
Environmental & Certifications
Compliance
•NFPA1801:2021
•Ex-certified according to ANSI/ISA 12.12.01-2015 and meets Class I Division 2 Groups C and D
•Class II Division 2 Groups F and G, Temperature Code T4/T135°C
Directives:
Certified according to NFPA 1801:2021 specification:
Vibration Impact acceleration resistance Corrosion
Viewing surface abrasion Heat resistance Heat and flame Product label durability
Drop: 2 m(6.6 ft.) on concrete floor (IEC 60068-2-31)
EMC: EN 61000-6-2:2005 (Immunity) EN 61000-6-3: 2011 (Emission) FCC 47 CFR Part 15 B (Emission)
Encapsulation: IP 67 (IEC 60529)
Humidity (Operating and Storage): IEC 60068-2-30/24 h 95% relative humidity 25°C to 40°C(77°F to 104°F)/ 2 cycles
Magnetic fields: EN 61 000-4-8, Test level 5 for continuous field (severe industrial environment)
Operating Temperature Range: -20°C to 60°C (-4°F to 140°F): infinity
150°C (302°F): 15 min.
260°C (500°F): 5 min.
Relative Humidity: 95% relative humidity 25°C to 40°C (77°F to 104°F) non-condensing
Shock: 25 g (IEC 60068-2-27)
Storage Temperature Range: –40°C to 85°C(–40°F to 185°F)
Tripod Mounting: UNC 1/4"-20 (adapter needed)
Vibration: 2 g (IEC 60068-2-6)
Power
Battery capacity: 4.4 Ah, at 20°C to 25°C (68°F to 77°F)
Battery operating time: Approx. 4 hours at 25°C (77°F) ambient temperature and typical use. This operating time is independent of camera mode.
Battery Type: Li Ion
Battery voltage: 3.6 V
Battery weight: 0.152 kg(0.3 lb.)
Charging system: Battery is charged inside the camera 2-bay charger Optional In-truck charger
Charging Temperature: 0°C to 45°C (32°F to 113°F)
Charging Time: 2 h to 85% capacity, charging status indicated by LEDs
Power Management: Automatic shutdown and sleep mode
Safety [power supply]: CE/EN/UL/CSA/PSE 60950-1
Start Up Time: <17 s. (IR image, no GUI)
Start-up time from sleep mode: <4 s.
Measurement & Analysis
Accuracy: ±4°C (±7.2°F) or ±4% of reading, for ambient temperature 10°C to 35°C (50°F to 95°F)
Auto Range: Yes, selectable on/off using FLIR Tools®
Automatic Hot Detection: Heat detection mode (the hottest 20% of the of scene is colorized)
Camera size (L x W x H): 120 x 125 x 280 mm (4.7 x 4.9 x 11 in.)
Camera weight incl battery: 1.1 ±0.05 kg (2.4 ±0.1 lb.)
Isotherm: Yes, according to NFPA
Object Temperature Range: –20°C to 150°C (–4°F to 302°F) 0°C to 650°C (32°F to 1202°F)
Set-up Commands: Local adaptation of units, date and time formats
Spot Meter: 1.0
General
Compatible with FLIR software: FLIR Tools®
Material: PPSU Silicon rubber Aluminium, cast Flame-resistant magnesium alloy
Packaging Size: 500 × 190 × 370 mm (19.7 × 7.5 × 14.6 in)
User: Interface
Display: 4 in. LCD, 320 × 240 pixels, backlit
Languages: English
Report Generation: Separate software (FLIR Tools)
Communication & Data Storage
File Formats: Standard JPEG
Image Storage: Standard JPEG; Image freeze: configurable
Image Storage Capacity: 200 files in total the total number of files is co-dependent on the number of saved video clips.
Image Storage Mode: IR only
Interface: Update from PC devices Data transfer to and from PC
Storage Media: Internal flash memory
USB:USB Mini-B
