Evikon E2407 Barometric Pressure Transmitter (-20~70 °C)
Manufacturer: Evikon Model: E2407 - Contact
Sensor type: digital combined P and T sensor
Measurement range: 450...1100 hPa. -20...+70 °C
Resolution: 0.1 hPa / 01 °C
Accuracy: ±1.5 hPa. ±0.8 °C
Sampling interval: 0.5...32000 seconds
Response time: ~1 second
Self-diagnostics: full functionality check at start-up
Warm-up time: ≤ 1 s
Power supply: 11...30 VDC, nominal 12 / 24 VDC
Power consumption: < 1.5 W
Digital interface: RS485, Modbus RTU protocol
Analog outputs: 2 × 4-20 mA / 0-10 V, user settable
Enclosure: white plastic with ventilation slots, wall mount, protection class IP20
Dimensions: H71 × W71 × D27 mm
Operating environment: residential, business and industrial indoor spaces
Operating conditions: -20...+70 °C, without condensation
