Pressure Capacity: 5T/50KN
Pressure Gauge: Manually adjustable pressure; pressure gauge adjustment accuracy: 5% [Pressure = Force / Sample Area]
Platen Size (mm, metric): 200200 / 250250 / 300300 / 350350 / 400400 / 450450 / 500*500 (mm)
Heating Platen Material: High-temperature resistant imported steel plate; surface carburized and quenched; specially treated for fast heat conduction,
parallel pressure maintenance without deformation, and wear resistance.
Platen Hardness: 50 – 60HRC
Platen Flatness: ≤ 0.03mm
Platen Parallelism: ≤ 0.16mm
Temperature Range: Room temperature – 250°C (Customizable up to 500°C)
Temperature Uniformity: 1.5°C (The larger the pressure plate, the higher the temperature, and the worse the temperature uniformity)
Temperature Controller: Precision module, combined with PLC touch screen control, touch screen internal display, numerical display.
Temperature Control Method: The temperature control motherboard provides precise control, with self-tuning and high-precision sensors. The temperature control accuracy is ± 1.0 ℃.
Timer: Touch screen display settings, time range 0.1S – 999min – 99hr
Heater: Heating mold with built-in cylindrical shape [packaging pressure plate temperature uniformity according to different power configurations based on pressure plate area, not the same power
Heating Time: From room temperature to 160°C, it takes about 15 minutes
Heating Platens: The hot plate can be set to control the temperature separately
Heating Method: Electric heating
Cooling Method: Natural cooling
Hydraulic System: Adopting CREE.Q1 air pressure control system, the piston of the high-precision cylinder driven by air without resistance performs smooth lifting and lowering; Manually apply pressure, maintain pressure, and release pressure
Cylinder Stroke: Max 150mm
Cylinder Speed: 11mm/s
Pressure Gauge Range: 0 – 200kg/sq.cm
Mold Opening Method: Fully automatic rise and fall (with manual and automatic dual functions)
Safety Devices: Safety protective cover, safety door
Number of Safety Devices: 4 of them
Mold Frame (Optional): Customize
Main Unit Dimensions: (W × D × H) 600 × 550 × 1550 mm
Power Supply Voltage: 3φ, AC220V
Air Source: 0.5 – 0.7mpa
Total Weight: ≈350kg
