Power Supply: AC 220 V, 50 Hz
Temperature Specifications
Temperature Control Range: RT+10℃~70.0℃
Temperature Fluctuation: ±0.5℃
Temperature Uniformity: ±2.0℃
Humidity Specifications
Humidity Control Range: 90.0%RH~98.0%RH (Temperature Range: 30.0℃~70.0℃)
Humidity Fluctuation: ±1.0% RH
Humidity Uniformity: ±3.0% RH
Lighting Specifications
Lamp Type: UV-A / UV-B
Wavelength Range: UV-A (280~315 nm) 40±10% W/㎡ / UV-B (315~400 nm) 40±10% W/㎡
Number of Lamps: 8
Distance Between Lamp Centers: 70±2 mm
Distance from Lamp Center to Specimen: 50±2 mm
Lamp Life: 1200 h
Spray Nozzle Quantity: 12
Irradiation Area: W100 * D400 ±2 mm
Material / Construction
Interior Material: SUS304 Stainless Steel
Exterior Material: SUS304 Stainless Steel
Insulation Material: 50 mm Thick Glass Wool
Blower: Axial Flow Fan
Humidifier: Steam-Type Humidifier
Dimensions
Inner Chamber Dimensions (mm): 1170 * 500 * 450 (WHD)
Outer Cabinet Dimensions (mm): 1370 * 1750 * 650 (WHD)
Capacity (L): 260
Weight (kg): 300
Ambient Operating Temperature Range: +5 ~ 35℃
Safety Features
Adjustable Specimen Overtemperature Protection
Heater Overtemperature Protection
Humidifier Overtemperature Protection
Automatic Equipment Shutdown in Case of Malfunction
Leakage Protection with Main Power Cutoff
