Control Mode: Touch Screen Control with Print Qutput
External Dimensions: 1100 x 700 x 1100 mm
Internal Chamber Volume: ≥20.5 cubic meters, with a glass observation door
Flame Application Time: 0~99 min and 99s (adjustable/programmable), accuracy +0.1s
Afterflame Time: 0~99 min and 99s (adjustable/programmable), accuracy +0.1s
Afterglow Time: 0~99 min and 99s (adjustable/programmable), accuracy +0.1s
Test Gas: Natural gas with over 98% methane content /37 M/m³ (coal gas is also acceptable)
Burner Dimensions Parameters: Inner diameter of nozzle 9,5 mm, effective length of nozzle 100 mm, with air adjustment holes
Sample Alignment Method: Motor-driven alignment of test specimens (front/back, left/right)
Combustion Angle: 20° 45° 90° (i.e.,0°) (adjustable)
Flame Height: Adjustable from 20 mm to 175 mm as required by standards
Flowmeter: Adopting the 105 ml/min standard
Gas Leak Detection: Gas Alarm Device (Optional)
Power Supply: AC 220V 50Hz
Additional Configurations: Lighting device, air extraction device, gas flow control valve, gas pressure gauge, gas pressure regulating valve, gas flowmeter, gas U-tube manometer, and sample fixture
