| Accuracy class | C3 | |
| Output sensitivity (=FS) | mV/V | 2.0 ± 0.2 |
| Maximum capacity (Emax) | kg | 100/150/200/250/500/750/1000/2000 |
| Maximum number of load cell intervals (nLC) | 3000 | |
| Ratio of minimum LC verification interval Y=Emax / Vmin | 7500 | |
| Combined error | %FS | ± 0.020 |
| Minimum dead load | %FS | 0 |
| Safe overload | %FS | 150 |
| Ultimate overload | %FS | 300 |
| Zero balance | %FS | ± 1.0 |
| Excitation, recommended voltage | V | 5 ~ 12 (DC) |
| Excitation maximum | V | 18 (DC) |
| Input resistance | Ω | 400 ± 20 |
| Output resistance | Ω | 351 ± 2 |
| Insulation resistance | MΩ | ≥ 5000 (50VDC) |
| Compensated temperature | ℃ | -10 ~+40 |
| Operating temperature | ℃ | -35 ~ +65 |
| Storage temperature | ℃ | -40 ~ +70 |
| Element material | Nickel plated alloy steel | |
| Ingress protection (according to EN 60529) | IP66 |
