Print Technology: Direct Thermal and Thermal Transfer
Resolution: 203 dpi
Max Print Width: 104 mm
Print Speed: 203 mm per second
Connectivity Interface: 802.11ac Wi-Fi and Bluetooth 4.1 (dual radio), (factory installed or field installable)
Memory: 512 MB Flash; 256 MB SDRAM 64 MB user available non-volatile memory 8 MB user available SDRAM
Barcodes: 1D, 2D
Media Roll Size: Minimum 0.25 in ~ 6.4 mm / Maximum 39.0 in ~ 991 mm
Ribbon Roll Length: 2.6 in./66 mm (300 m); 1.34 in./34 mm (74 m)
Dimensions (L x W x H):
Direct Thermal: 221 mm L x 177 mm W x 151 mm H
Thermal Transfer: 267 mm L x 202 mm W x 192 mm H
Weight:
Direct Thermal: 3.6 lbs./1.6 kg
Thermal Transfer: 5.5 lbs./2.5 kg
Media Sensors: Full width, movable reflective/black mark sensor; multi-position gap/transmissive sensor
Printing Languages: ZPL II; EPL 2; XML; ZBI; PDF Direct
Battery: Powers printer to support full-shift printing at max print speed; supports all media handling options
Operating Temperature: 40° to 105° F/4.4° to 41° C
Storage Temperature: -40° to 140° F/-40° to 60° C
Humidity: 5% to 95% non-condensing
1D Barcodes: Code 11, Code 39, Code 93, Code 128, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2- or 5-digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar and Planet Code
2D Barcodes: Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, MicroPDF, Aztec
Fonts and Graphics: 16 resident expandable ZPL II bitmap fonts, two resident ZPL scalable fonts, five resident EPL2 expandable fonts, native open-type font support, Unicode compliant. Chinese units include SimSun Simplified Chinese font 64 MB user available non-volatile memory, 8 MB user available SDRAM
