Print Technology: Direct Thermal
Resolution: 230 dpi
Max Print Width: 2.2 inch~56 mm
Print Speed: 8 inch/203 mm per second
Connectivity Interface: Field installable RS-232 auto-sensing Serial; Factory installed or field installable wireless dual radio – 802.11ac Wi-Fi and Bluetooth Classic 4.2
Memory: 512 MB Flash; 256MB DDR3 SDRAM
Barcodes: 1D, 2D
Media Roll Size: Minimum 0.25 in ~ 6.35 mm / Maximum 39.0 in ~ 991 mm
Ribbon Roll Length: 1.34 in./34 mm (74 m)
Dimensions (L x W x H): 220 mm L x 115 mm W x 151 mm H
Weight: 2.36 lb./1.07 kg
Media Sensors: Full width, movable reflective/black mark sensor; multi-position gap/transmissive sensor
Printing Languages: ZPL II; EPL 2; XML; ZBI; PDF Direct
Battery: Powers printer to support full-shift printing at max print speed; supports all media handling options
Operating Temperature: 40° to 105° F/4.4° to 41° C
Storage Temperature: -40° to 140° F/-40° to 60° C
Humidity: 5% to 95% non-condensing
RFID (Option): Available as RFID, supporting UHF EPC Gen 2 and RAIN RFID protocols, using Adaptive Encoding Technology and Zebra's RE40 RFID Encoder/Reader
1D Barcodes: Code 11, Code 39, Code 93, Code 128, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2- or 5-digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar and Planet Code
2D Barcodes: Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, MicroPDF, Aztec
Fonts and Graphics: 16 resident expandable ZPL II bitmap fonts, two resident ZPL scalable fonts, five resident EPL2 expandable fonts, native open-type font support, Unicode compliant. Chinese units include SimSun Simplified Chinese font 64 MB user available non-volatile memory, 8 MB user available SDRAM
