Polarization: Left-hand circular
Dimensions: 391 mm x 275 mm X 12 mm / 15.39 in. x 10.82 in x 0.47 in
Connector: N-Type Female
Connector Location: Pigtail - Side
Mounting Options: Flush mount
Weight: 2.2 lbs. / 1.0 kg
Casing/Materials: Aluminum with Kydex Casing
Frequency Range: EU: 865 – 868 MHz / US: 902 – 928 MHz
VSWR (Return Loss): 1.4:1
Gain: 7.0 dBic
Front to Back Ratio: 22 dB
3 dB Beam Width: 75° in horizontal plane, 48° in vertical plane
Maximum Power: 6 Watts
Axial Ratio: < 2 dB
Operating Temperature: -20° to +55°C / -4° to +131°F
Storage Temperature: -30° to +65°C / -22° to +149°F
Standard: IP54
Vibration Resistance: IEC-68-2-6 (10 to 150 Hz, 0.5 g, one hour in each of two axes) (Random Vibration)
Humidity: IEC-68-2-30 (-13° F to 104° F, -25° C to 40° C) 24 hour cycles of 90% relative humidity
