Polarization: RHCP (Right Hand Circular Polarized)
Dimensions: 150 mm x 150 mm x 14 mm/ 5.9 in. x 5.9in x 0.55 in.
Connector: SMA female
Connector Location: Side connector
Mounting Options: Flush mount
Weight: 0.25 kg/0.55 lbs
Casing/Materials: UV-Resistant ABS
Frequency Ranges: ETSI: 865-868 MHz / FCC: 902-928 MHz
VSWR (Return Loss): 1.4 typical
Gain: 5.5 dBiC typical
Front to Back Ratio: -10 dB
3 dB Beam Width: 115° in both planes
Maximum Power: 3 Watts
Axial Ratio: 2 dB typical
Operating Temperature: -40° to +65°C/-40° to +149°F
Storage Temperature: -40° to +65°C/-40° to +149°F
IP Sealing: IP68
Vibration: IEC60068-2-64
Humidity: 72 Hours @ 85° C relative humidity
