Polarization: Right-hand circular
Dimensions: 250 mm x 250 mm x 14 mm/ 9.85 in. x 9.85 in x 0.55 in
Connector: SMA female
Connector Location: Side mounted
Mounting Options: Flush mount or VESA mount
Weight: 1.6 lbs./0.75kg
Casing/Materials: UV-Resistant ABS
Frequency Ranges: EU: 865 – 868 MHz / US: 902 – 928 MHz
VSWR (Return Loss): 1.3:1
Gain: 8.5 dBic
Front to Back Ratio: 20 dB
3 dB Beam Width: 68° in both planes
Maximum Power: 3 Watts
Axial Ratio: 1 dB
Operating Temperature: -20° to +55°C/-4° to +131°F
Storage Temperature: -30° to +65°C/-22° to +149°F
IP Sealing: IP67
Vibration: MIL-STD-810G
Humidity: 72 Hours @ 85°C relative humidity
