1. Test Chamber Size : (W) 1,700mm x (D) 900mm x (H)2,000mm
2. Hood Size : (W) 1,700mm x (D) 900mm x (H)2,000mm
3. Duct Size : Ø400 x 2,000(L) mm
4. Exhaust Fan : Armature Voltage : 180V / Revolution : 3000rpm / 1.5HP
5. Heat Source
Section Burner : (W)150mm x (D) 500mm / Nozzle : 20 ea/ 0.1m2 / STS 304
Multiple Burner : (W) 100mm x (D)420mm / Jet burner 15 ea / STS 304
6. Mass Flow Controller
Gas(C3H8) Mass Flow Controller 150 SLPM / Signal output : 0 ~ 5V / Accuracy ±1 of F.S
Air Mass Flow Controller 300 SLPM / Signal output : 0 ~ 5 V / Accuracy ±1 of F.S
7. Vessel for water Size : Ø350 x L500 mm
8. Booster pump : AC 220V / Max 20Bar
9. Calorimeter cube Size : (W)38mm x(D)38mm x (H)38mm
K-type Thermocouple : Ø3.2, (L)235mm
10. DAQ System : 2 channel Analog Input / Output Module / Range : ± 10VDC
2 channel Digital Input / Output Module / Range : ± 5VDC
Size: (W)1,7000 X (D)900 X (H)2,000 mm
Power: 220VAC, 50Hz, 10A
Weight: 300kg
Utilities: LPG Gas Cylinder
