Capacity (optional): 100, 200, 500 N; 1, 2, 5, 10, 20 kN
Unit (Switchable): kgf, gf, Ton, lbf, N, kN, or by user`s definition
Load Resolution: 1/50,000
Load Accuracy: ±1%
Load Range: Rangeless (full scales at the same amplification)
Stroke (exclude the grips): 1100 mm
Effective width: 410 mm
Test Speed: 0.000~999 mm/min
Speed Accuracy: ±1%
Stroke Resolution: 0.01 mm
Sample Rate: 16 times/sec
Communication Interface: RS 232(U58 optional)
Display method: U25 (can display and print test value, maximum force, break value, modulus, force, stress, etc.)
Motor: AC servo motor
Dimension (WxDxH): Main Unit (Height exclusive of footpad): 111 × 64 × 233 cm
Weight (approx.): Main Unit: 384kg
Power: 1∮, 220V,50/60Hz,15A or specified by us
