1. Burner: Φ9.5mm ± 0.3mm bunsen burner
2. Dip angle:00, 200, 450 (manual adjustment)
3. Flame height: 20mm ± 2mm to 180mm±10mm (adjustable)
4. Flame time: 0-999.9s±0.1s (adjustable)
5. After flame time: 0-999.9s±0.1s (auto record, manual pause)
6. After glow time: 0-999.9s±0.1s (auto record, manual pause)
7. Fuel gas: 98% methane
8. Flow and pressure record: flowmeter and manometer
9. Test temperature range: 0-10000C
10. Flame temperature required: heat up from 1000C±50C to 7000C±30C within the time of 44s±2s and 54s±2s
11. Thermocouple: diameter of 0.5mm K type thermocouple (2 pieces)
12. Test background: black
13. Volume of chamber: 0.75 CBM
14. Dimension of apparatus: 1100mm(W)*700mm(D)*1300mm (H)
15. Power supply: AC220V, 50Hz, ≤500W
