YuYang YY1023 Xenon Weathering Aging Test Chamber

Inner size: 1170×450×500(L×W×H)MM

Outside dimension: 1300×550×1480(L×W×H)MM

Whole chamber material: 304# stainless steel

Temperature range: RT+10℃~70℃

Temperature uniformity: ±1℃

Temperature fluctuation: ±0.5℃

Temperature control: PID SSR control

Humidity range: ≥90%RH

Controller: Korean TEMI 880 programmable controller, touch screen, LCD display

Control mode: Balance temperature humidity control (BTHC)

Communication port: Be able to control the machine via computer using TEMI control software through RS-232 port on the machine

Test cycle setting: Illumination, condensation and water spray test cycle is programmable

Distance from specimen to lamp: 50±3mm (adjustable)

Center distance between the lamps: 70mm

Lamp power & length: 40W/Piece, 1200mm/Piece

Lamps amount: 8 pieces of UVA-340nm imported Philip lamps

Lifetime of lamp: 1600Hours

Irradiance: 1.0W/m2

Wavelength of ultraviolet light: UVA is 315-400nm

Effective irradiation area: 900×210mm

Irradiation black panel temperature: 50℃~70℃

Standard specimen size: 75×290mm/24 pieces

Water depth for water channel: 25mm, automatically control

Testing time: 0~999H, adjustable

Power: AC220V/50Hz /±10% 5KW

Protection: Overload short circuit protection, over temperature protection, water lacking protection

Corresponding standard: ASTM D4329,D499,D4587,D5208,G154,G53;ISO 4892-3,ISO 11507;EN534;EN 1062-4,BS 2782;JIS D0205;SAE J2020
