Number of slots: 3
Display: Color LCD, 320 × 240 dots
Remote interface:
GPIB: IEEE-488 compatible, protocol: IEEE-488.2 compatible
Ethernet: IEEE802.3 compatible, connector: RJ-45 x 1, transmission method: Ethernet (100BASE-TX), protocol: TCP/IP
USB: USB Rev1.1 compatible, connector: USB type B x 1, protocol: USB-TMC
External storage interface: USB (USB Rev2.0 compatible, connector: USB type A x 1, applicable device: USB mass storage class flash memory)
Trigger In: Connector: BNC x 1, TTL level, Pulse width: 50 μs or more, Impedance: approx. 5 kΩ
Trigger Out: Connector: BNC x 1, TTL level, Pulse width: approx. 50 μs, Impedance: approx. 100 Ω
Interlock connector: BNC connector
Operation environment: Ambient temperature 5 to 40°C; Ambient humidity 20 to 80% RH (no condensation); Altitude 2000 m or less
Storage environment: Ambient temperature -20 to 60°C; Ambient humidity 20 to 80% RH (no condensation); Altitude 3000 m or less
Power requirement: 100 to 240 V AC, 50/60 Hz
Power Consumption (including modules): 170 VA
Dimensions: Approx. 212(W) × 132.5(H) × 400(D) mm (excluding protrusions)
Weight: Approx. 6 kg
