Max. Scale Value: 30/100/300/1000/3000 µA DC
Approximate Internal Resistance and Consumed Power: 5/6.8/2.8/0.9/0.3 kΩ
Operating Principle: Permanent magnet moving coil type
Class: JIS C 1102: 1997 Class 1.0
Operating Position: Horizontal
Scale Length: Approximately 135 mm (Deflection Angle: 90°)
Needle: Bladed Needle (red)
Linemax: 250V (Ammeters only)
Operating Temperature Range: 0 ~ 40°C
Operating Humidity Range: 30 ~ 75% RH
Storage Temperature Range: -10 ~ 50°C
Storage Humidity Range: 25 ~ 80% RH
Dimension: 113 x 106 x 46 mm
Weight: 0.35 kg
