Sensitivity: 100 mV/N
Measuring Range: 50 N pk
Nonlinearity: ≤5%
Resolution: 2 mN rms
Resonant Frequency: 70 kHz
Low Frequency: 1 Hz
Head Weight: 15 g
Head Diameter: Φ14 mm
Hammer Length: 115 mm
Output Connector: M5
Common Parameters
IEPE Output Mode:
Excitation voltage: +18 ~ +28V;
Constant current: 2 ~ 10mA;
DC offset:10 ~ 14VDC;
Output impendance: ≤100Ω;
Charge Output Mode:
Insulation Resistance: ≥10¹²Ω
