Yamato FO611 Standard Electric Furnace (17.5L, 3kW)

Operating temp. range: 100 to 1,150℃

Temp. control accuracy: ±2.0℃（at 1,150℃）

Max. temp. reaching time: Approx. 80min.

Chrome-free electro-galvanized steel plate, Chemical proof painting

Internal material: Alumina fiber

Sensor: R-thermocouple

Heater: Iron-chrome wire 3kW

Exhaust port: 20 mm I.D. (upper part)

Cooling Fan Type: Axial fan motor

Temp. controller: PID control by microprocessor

Accessories: 1 exhaust cap, 1 thermal fuse

Internal dimensions（W×D×H mm）: 250×350×205mm

External dimensions（W×D×H mm）: 507×604×677mm

Remarks(dimensions): 17.5L

Power Source: Single Phase AC200V 16A Plug is not attached, Electric code length is 2m

Weight: 52kg

Datasheet
