Yamato DT411 Clean Oven (91L)

Circulation method Forced air circulation

Operating temperature range: RT +30~260°C

Temp. control accuracy: ±0.3°C (at 260°C) JTM K05

Temp. distribution accuracy: ±4.0°C (at 260°C) JTM K05

Max. temp. reaching time: Approx. 80 min

Clean level: Class 100

Interior material: Stainless steel

Exterior material: Cold rolled steel plate with melamine resin baking finish

Temp. control system: PID control with a micro processor

Heater: Stainless pipe heater

Heat insulating material: Glass wool

Internal dimensions (W×D×H): 450×450×450mm

External dimensions (W×D×H): 700×1025×1570mm

Internal capacity: 91L

Power supply: AC220V / 380V Three phase

Weight: 200 kg
