System: Vacuum drying by decompressed chamber direct heating
Operating temperature range: 40~200°C
Operating pressure range: 101~0.1kPa (760~1 Torr) at absolute pressure
Temp. control accuracy: ±1.5 °C (at 200°C) JTM K05
Max. temp. reaching time: Approx. 100 min.
Heater circuit control: Triac zero-cross control
Interior material: Stainless steel
Exterior material: Cold rolled steel plate baking coating
Temp. control method: PlD control by microprocessor
Heater: Mica heater 3.15 kW
Heat insulating material: Rock wool
Internal dimensions (WxDxH): 600×600×600mm
External dimensions (WxDxH): 820×819×1650mm
Internal capacity: 216L
Power source: AC220V Single phase 16A
Weight: Approx. 310kg
