Yamato DH412S Anti-explosion Fine Oven (91L, 2.7kW)

System: Forced convection and ventilation

Operating temperature range: RT +10~360°C

Temp. control system: PID control with a micro computer

Heater: Stainless steel pipe heater with fins 2.7kW

Fan: Axial fan (Condenser motor: 20W)

Cable port: I.D. 33 mm×1 pc. (rear)

Heat insulating material: Ceramic fiber

Internal dimensions (W×D×H): 450×450×450mm

External dimensions (W×D×H): 1050×620×1240mm

Internal capacity: 91L

Power supply: Single phase: AC220V, 13A

Weight: 130kg

Stainless wire shelf / bracket: 2 pcs / 4 pcs
