Method: External opened circulation
Operating temperature range: -10 to +80°C
Temperature control accuracy: ±0.1°C (JTM K05) at fluid temp.10°C
Cooling capacity: Approx. 450W (387Kcal/h), at fluid temp.15°C
Temperature control: PID control
Temperature sensor: Temp. controller: Pt thermal resistance, overheat protection: K thermocouple
Heater: 900W
Temperature setting, display: Digital setting and display
Refrigerator, refrigerant: Air cooling, 200W, R404A
Circulating pump: Magnetic drive pump
Unit circulation ability (50/60Hz), Max. flow, Pump capacity: 5.4/6.2L/min, (10.0/11.0L/min)
Unit circulation ability (50/60Hz), Max. lift, Pump capacity: 3.5/5.0m, (4.9/6.9m)
External circulation nozzle: O.D.13mm of water outlet and return port
Operating environmental temp. range: 5 to 30°C
Accessories: Circulating heat preservation pipe-1, Pump circulating tube-1, Hoop-4, Drain pipe-1
External dimensions（W×D×H mm）: 410×460×550mm
Remarks(dimensions): Bath capacity 1.5L, Bath dimension D.120×D200mm
Power Source: AC115V/AC220V Single-phase with step down transformer
Weight: 40kg
