Yamato CFI 701 Cooling Water Circulator (5L, 1000W)

Type: High-lift type

Circulation type: Closed System Circulation/Tap Water or Anti-freezing liquid

Operating temp. range: 5 to 30℃

Temp. fluctuation (JIS): 0.2°C

Cooling capacity (at Liquid Temp. 20°C): Approx. 1,000W

External circulation flow rate (50/60Hz): Approx. 15/18L/min

Pump max. lift (50/60Hz): Approx. 35/48m

Tank: Polyethylene

Temp. control: Refrigerator inverter control

Temp. sensor: Pt100Ω, T thermocouple

Temp. setting/display: Digital setting/display

Refrigerator/coolant: Air-cooling inverter type/R410A

Heat exchanger: Plate type heat exchanger, SUS316

External circulation Nozzle: Nozzle is option, Rc1/2

Circulation pump: Turbine Pump 370W

Accessories: Lid, Drain hose ( I.D. 9mm x 500mm), Drain hose nozzle (O.D. 10mm)

External dimensions（W×D×H mm）: 380×520×690mm

Remarks(dimensions): Water bath capacity approx. 5L

Power Source: AC115V/AC220V Single-phase with step down transformer

Weight: 56kg
