Test Current: Three-phase test: 20A+20A, 10A+10A, 5A+5A, 1A+1A
Phase separation test: 40A, 20A, 10A, 5A, 1A, 0.2A
Test Range:
40A: 100.0μΩ ~ 0.5Ω
20A: 500.0μΩ ~ 1Ω
10A: 1mΩ ~ 2Ω
5A: 10mΩ ~ 4Ω
1A: 100mΩ ~ 20Ω
0.2A: 1Ω ~ 100Ω
20A+20A: 200μΩ~0.3Ω
10A+10A: 500μΩ~0.6Ω
5A+5A: 10mΩ ~ 1.5Ω
1A+1A: 100mΩ ~7Ω
Resolution: 0.1μΩ
Accuracy: ±(reading×0.2%+2 words)
Dimensions: 430mm × 320mm × 230mm
Weight: 12kg
Operating Conditions: Temperature: -10°C ~ 50°C
Humidity: ≤ 85%RH
Power Requirements: AC220V ± 10%
Power frequency: (50±1)Hz
