Output current:
Single phase: 20A, 10A, 5A, 1A, 0.1A, 10mA, <1mA
Three phase: 10A+10A, 5A+5A, 1A+1A, 0.1A+0.1A
Measuring range:
Single phase:
20A level: 0.5mΩ ~ 1Ω
10A level: 1.0mΩ ~ 2Ω
5A level: 10mΩ ~ 4Ω
1A level: 0.1Ω ~ 20Ω
0.1A level: 2.0Ω ~ 200Ω
10mA level: 50Ω ~ 2kΩ
<1mA range: 500Ω ~ 25kΩ
Three phase:
10A + 10A gear: 0.5mΩ ~ 0.8Ω
5A + 5A level: 10mΩ ~ 1.6Ω
1A + 1A level: 0.1Ω ~ 8.0Ω
0.1A + 0.1A gear: 2.0Ω ~ 80Ω
Accuracy: ±(reading × 0.2% + 2 words)
Power supply: AC220V ±10%, 50/60Hz
Operating temperature: -10°C ~ +50°C
Relative humidity: <90%, no condensation
Instrument volume: 400 × 315 × 223 mm
Instrument weight: 9kg
