Test current: <20mA, 2.5A, 5A, 10A, 20A, 40A
Test range:
50μΩ–500mΩ (40A)
100μΩ–1Ω (20A)
500μΩ–2Ω (10A)
1mΩ–4Ω (5A)
2mΩ–8Ω (2.5A)
10Ω–20kΩ (<20mA)
Accuracy: ±(0.2% + 2 digits) for 40A–10A ranges
Accuracy: ±(0.5% + 2 digits) for <20mA range
Minimum resolution: 0.1μΩ
Display: LCD monitor (resistance display with 4 significant digits)
Data storage: 1000 groups
Working environment:
Ambient temperature: 0°C ~ 40°C
Relative humidity: <90%RH, no condensation
Power supply: AC 220V ±10%, 50Hz ±1Hz, Fuse 10A
Size:
Host: 405 × 230 × 355 (mm)
Wire box: 360 × 260 × 180 (mm)
Weight:
Host: 15.1kg
Wire box: 5.75kg
Test lead length: Standard 13 meters (can be customized)
Maximum power consumption: 1000W
