1. The number of simulated fault waveforms is not less than 40
2. Near-end faults are tens of meters, and far-end faults are hundreds of meters
3. Low-resistance fault simulator: 0 ohm~hundred ohm level
4. Open circuit fault simulator: G ohm~infinity
5. Leakage high-resistance fault simulator: k ohm level~hundred M ohm level
6. Flashover high-resistance fault simulator: flashover voltage range is several kV~tens of kV
7. 2500V megohmmeter insulation resistance
a. Open circuit state is greater than 1.5GΩ
b. Short circuit state: 0 MΩ
c. Low resistance state is about 5MΩ
d. Leakage state is about 2MΩ
e. Flashover state is about 1GΩ
8. Rated voltage of simulated cable: DC 35kV
9. Remote control distance: 10 meters
10. Continuous working time: 8 hours
11. Cabinet size: 860mm long × 660mm wide × 2030mm high
12. Cabinet weight: 300KG
13. Use conditions:
a. Ambient temperature -30℃~ +70℃
b. Relative temperature RH≤85% (25℃)
c. Altitude h≤1000m
