Calibration: White, Zero, UV
Communication Interface: USB 2.0
Dimensions: 56cm, 22cm, 31cm (length, width, height)
Embedded NetProfiler Support: Yes
Humidity: 5% to 85%, non-condensing
Illumination Spot Size: 25mm, 17mm*, 10mm, 6mm, 3.5mm*
Inter-Instrument Agreement: 0.15 ΔE*ab avg.
Internal Temperature & Humidity Sensor: Yes
Lamp Life: ≥1,000,000 measurements
Laser Transmission Targeting : Yes
Light Source: Pulsed Xenon, D65 calibrated
Measurement Cycle Time: ≈ 2.5 seconds
Measurement Geometry: d/8°
Measurement Spot: 19mm, 10mm, 5mm, 2.5mm
Measurement Time: ≈ 2.5 seconds
Operating Temperature Range: 5°C to 40°C
Optional UV Filters: 400, 420, 460
Photometric Resolution: 0.01%
Reflectance Aperture(s): 3 std / 2 optional
Sample Preview: Door and Video
Service Indicator: Status panel
Shipped Weight: ’25kg
Short Term Repeatability – White: .03 ΔE*ab RMS on white ceramic
Software Development Kit: XDS4
Spectral Analyzer: 2D CCD array holographic grating
Spectral Interval: 10 nm (default); 20nm
Spectral Range: 360nm-750nm
Spectral Reporting: 10 nm (default); 20nm
Status Panel: Yes
Storage Temperature Range: -20° to 50°C
Transform Support: Embedded
Transmission Aperture(s): 3
Voltage: 100 to 240 VAC / 50 to 60Hz
Warm Up Time: None
Weight: 20.5kg
