XP Power JWE0624S3V3 Isolated DC-DC CONVERTER, 6W, 4:1, DIP16

Width: 13.7 mm (0.539 in)

Height: 8 mm (0.315 in)

Length: 23.8 mm (0.937 in)

Industry: Industrial

Unit Weight: 19.570 g

Output Power: 6 W

Input Voltage: 9 V to 36 V

Mounting Style: Through Hole

Isolation Voltage: 1.5 kV

Number of Outputs: 1 Output

Input Voltage - Max: 36 V

Input Voltage - Min: 9 V

Input Voltage, Nominal: 24 V

Output Current-Channel 1: 1.5 A

Output Voltage-Channel 1: 3.3 V

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 40 C
