Width: 24 mm
Height: 17.5 mm
Length: 44 mm
Approvals: EN60939-2, ANSI/UL1283
Compliance: EN60939-2, ANSI/UL1283
Inductance: 2 x 0.8 mH
Capacitance: 0.1 uF, 6600 pF
Filter Type: 1-Phase EMI/EMC Filter
Unit Weight: 43 g
Current Rating: 6 A
Mounting Style: Chassis Mount
Voltage Rating: 250 VAC
Leakage Current: 600 uA
Termination Style: Quick Connect
Operating Frequency: 0 Hz to 400 Hz
Maximum Operating Temperature: + 110 C
Minimum Operating Temperature: - 40 C
