Capacity: 50N~100N
Non-linearity: ≤±0.5%F.S.
Repeatability: ≤±0.05%F.S.
Zero balance: ±5%F.S.
Operating temp range: -20~80°C
Compensated temp range: -10~40°C
Insulation: ≥2000MΩ/50VDC
Recommended excitation voltage: 5VDC
Safe load limit: 300%F.S.
Temp effect on output: ≤0.2%F.S./10°C
Temp effect on zero: ≤0.2%F.S./10°C
Long-term crosstalk error: ≤3-5%F.S.
Protection class: IP65
Cable size: φ2.4*3m+Lemo14 PIN plug (Option)
Details
