Motion System
+ Motion
System: High Precision Servo System
+ Resolution:
X axis: ±0.02mm; Y axis: ±0.02mm; Z axis: ±0.02mm; θaxis: ±0.1°
+ Stroke:
X axis: 1000mm; Y axis: 500mm; Z axis: 40mm
+ Pick
& Place Header Accuracy: ±0.07mm
+ Operable Chip Size: Minimum: 2x2mm; Maximum: 25x25mm
+ Maximum Throughput: 1200
Units Per Hour
Vision System:
+ Camera:
Downward CCD camera for sockets / pick & place spots positioning. 512×512
pixels
+ Field
of View: 30x30mm
Power
Consumption: 1.5KVA
Air:
+ Pressure: 0.6MPa
+ Consumption: 30
liters/min
Size:
+ Main
Machine: 820(L)×640(W)×1550(H)mm
+ Auto
Tray: 1100(L)×380(W)×1300(H)mm
+ Tape-Out:
1100(L)×380(W)×1300(H)mm
Weight:
Main machine: 248kg
PC
Interface: USB 2.0, LAN
Included accessories:
+ 4
x SuperPro 7500
+ Built-in
Industrial PC with Windows 7
+ 19"
LCD Display
+ Keyboard
and mouse
Optional accessories:
+ Socket
Adapters (Socket Pressing)
+ Automated
Tray Handler
+ Tape-out
Packing Handler
+ Electric
Tape-in Feeder
+ Laser
Marker
+ Tube
In Device
+ Tube
Out Device
+ Tape
Ink Marker
+ Auto
Tray Ink Marker
+ Nozzles
