Color: Green
Pitch: 10.16 mm
Height: 8.1 mm
Length: 45.72 mm
Current Rating: 14 A
Mounting Angle: Vertical
Mounting Style: PCB Mount
Voltage Rating: 300 VAC
Wire Gauge Max: 14 AWG
Wire Gauge Min: 30 AWG
Contact Plating: Nickel
Contact Material: Copper Alloy
Housing Material: Polyamide (PA)
Wire Gauge Range: 30 AWG to14 AWG
Connection Method: Spring Clamp
Termination Style: Through Hole
Flammability Rating: UL 94 V-0
Number of Positions: 5 Position
