Pitch: 2.54 mm (0.1 in)
Application: Wire-to-Board
Row Spacing: 1.5 mm (0.059 in)
Unit Weight: 490 mg
Housing Color: Red
Latching Type: Unlatched
Contact Gender: Pin (Male)
Current Rating: 1 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 2 Row
Voltage Rating: 100 V
Contact Plating: Tin
Contact Material: Phosphor Bronze
Housing Material: Polyester
Termination Style: IDC
Flammability Rating: UL 94 V-0
Number of Positions: 8 Position
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
