Pitch: 3 mm (0.118 in)
Application: Wire-to-Board
Row Spacing: 3 mm (0.118 in)
Unit Weight: 2 g
Housing Color: Black
Latching Type: Unlatched
Contact Gender: Pin (Male)
Current Rating: 5 A
Mounting Angle: Straight
Mounting Style: Through Hole
Number of Rows: 2 Row
Voltage Rating: 250 V
Contact Plating: Tin
Contact Material: Copper Alloy
Housing Material: Liquid Crystal Polymer (LCP)
Termination Style: Solder Pin
Flammability Rating: UL 94 V-0
Number of Positions: 14 Position
Insulation Resistance: 1 GOhms
Termination Post Length: 3.2 mm (0.126 in)
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
