Pitch: 5.7 mm (0.224 in)
Application: Wire-to-Board, Signal
Row Spacing: 5.7 mm (0.224 in)
Housing Color: Black
Contact Gender: Pin (Male)
Current Rating: 26 A
Housing Gender: Female
Mounting Angle: Straight
Mounting Style: Through Hole
Number of Rows: 2 Row
Voltage Rating: 600 VAC
Contact Plating: Tin
Contact Material: Copper Alloy
Housing Material: LCP
Termination Style: Solder
Flammability Rating: UL94 V-0
Number of Positions: 4 Position
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
