Measurement range：
50A 0~10mΩ
100A 0~5mΩ
150A 0-3.333mΩ
200A 0-2.500mΩ
Resolving power:
0~99.99μΩ 0.01μΩ
100.0~10000.0μΩ 0.1μΩ
Test flow: DC50A, 100A,150A,200A four fixed output
Measurement accuracy: ±(0.5% rd+2d)
Working time optional: fast, 10 seconds, 30 seconds, 60 seconds
Display mode: 4 inch touch screen
Communication mode: U disk to store
Working power: AC220V±10% 50Hz
The whole machine power: 1000W
The maximum storage records: 200
Working environment: temperature -10 ℃ ~ 40 ℃ humidity ≤ 80 % RH
Body size: 390×300×200 mm3
Weight: 7kg (without accessories)
