Test current: 1mA 10mA 1A 5A 10A
Measurement range:
1mA：10Ω~20KΩ
10mA：1Ω~2KΩ
1A：10mΩ~20Ω
5A：1mΩ~4Ω
10A：1mΩ~2Ω
Measurement accuracy: ± (0.2% full-scale ± 2 words)
Data storage: 255 of them
Display: liquid crystal display, Note:The resistance is displayed as 4 1/2 bits
Maximum resolution: 0.1μΩ
Power supply: AC 220V±22V,50Hz±2 Hz (note: Insurance pipe 5A)
Maximum power consumption: 300W (note: When the test current is 10A)
Working environment: Environmental temperature:0°～40° Relative humidity:≤80%
Volume: 400x200x280mm3
Weight: 9kg
