Rated output voltage: 0~60kV (AC RMS) and below
Output frequency: 50Hz
Resonance voltage waveform: Pure sine wave, waveform distortion rate ≤1%
Work system: Full power conticontrol consolenuous working time of 1min
Quality factor: 10~40
Maximum test capacity: 3000kVA and below
Working power supply: 380V±15%, Power frequency 50Hz
Control console: 30kW
Voltage regulator: 30kVA(electric)
Reactor (dry): 200kVA/25kV Adjustable one
Excitation transformer (dry): 30kVA dry
Voltage divider: 30kV
Scope of application: hydrodynamo.0.4～1.0μF.(10kV/40MW)
