- Power source: DC6V alkaline dry battery(1.5V AAA×4) keeps a continuous work for 20 hours
- Test way: Clam-on CT
- Transmission way: Wireless transmission with linear transmission distance about 30m
- Display mode: LCD: 128dots×64dots; Blue screen, backlight, suitable for dark places
- LCD dimension: Display area: 44mm×27mm
- Tester size (Width × Height× Thickness):
+ Main engine: 75mm×170mm×30mm
+ HV Current Clamp：76mm×255mm×31mm
+ LC Current Clamp：175mm×70mm×38mm
- Clamp Dimension :
+ HV Current Clamp:φ48mm
+ LC Current Clamp: φ25×30mm
- Sampling speed: 3 times/second
- Measurement range
+ High voltage detector: 0.1mA～1000A
+ Low-voltage current clamp: 0.01mA～10A
- Resolution:
+ High voltage detector: 0.1mA
+ Low-voltage current clamp: 0.01mA
- Gearing: Automatic gearing
- Measuring accuracy of the primary circuit(23℃±3℃,<80%RH)
+ 0.0mA～299mA: ±1%±3dgt
+ 0～10.0A: ±1.0%±5dgt
+ 10.0A～49.9A: ±2%±5dgt
+ 50A～199.9A: ±3%±5dgt
+ 200A～600A: ±4%±5dgt
+ 601A～1000A: ±5%±5dgt
- Measuring accuracy of the secondary circuit: 0～10A: ±0.5%±5dgt(23℃±3℃,<70%RH)
- Ratio: Max. ratio is 1:10 million (1.0K7)
- Data storage: 3,000 sets
- Line voltage: Test for lines bearing voltage below 60kv
- Weight
+ Main engine: about 240g (including battery)
+ High voltage detector: about 335g (including battery)
+ Low-voltage current clamp: 150g
+ Total weight: 5kg(including insulation rod and battery)
- External interference: No super strong electromagnetic field; no same frequency interference of 433 MHz and 315 MHz
- Working temperature and humidity: -25℃～45℃; 80%Rh
- Storing temperature and humidity: -10℃～60℃；70%Rh
- Insulation rod size: φ32mm, 1m/know (standard configuration: five knots), extendable
- Length of the lead of LV current clamp: Standard: 2 meters
- Insulation strength:
+ High voltage detector: AC100kV/rms
+ Main engine and low-voltage current clamp: AC1000V/rms
- Structure: Anti-drip II(high voltage detector)
Accessories
- HV tester
- Host
- LV Current Clamp
- Isulating Rod
- Serial Line
- Manual, Report, Certificate
