The range of testable grounding resistance:
0 -500KΩ (when the system voltage is 220V)
0 -250KΩ (when the system voltage is 110V)
0 -50KΩ (when the system voltage is 48V)
0 -10KΩ (when the system voltage is 24V)
The output power of the signal generator: ≤ 0.2W
The ground impedance distribution capacitance value: The ground capacitance of single circuit branch ≤ 8uF
The total system ground capacitance: ≤ 100uF
The applicable DC system voltage: 220V±10%, 110V±10%, 48V±10%, 24V±10%, or other voltage ranges suggested by the user
The environment temperature: -35℃～+55℃
The relative humidity: ≤95%
Total mass: 2.8 kg
Package size: 450x180x360 mm
Outline dimension : 460x240x120 mm
