Rate Power: 160kW
Peak Power: 240kW(60S)
Rate Voltage: 400V
Voltage range: 24-800V
Rated Current: 400A
Peak Current: 600A
Relief Device: 15kW (External)
AC features
Phase number: 3-phase 4-wire+PE
Voltage: 380V±10%
Frequency: 50Hz±5Hz
DC features
Voltage range: 24v—maximum voltage (continuously adjustable)
Display accuracy: ≤0.5%FS
Output accuracy: ≤0.5%FS
Source effect: ≤0.2%FS
Load effect: ≤0.2%FS
Ripple (Vrms): ≤0.5%FS
Response time: ≤10mS（10%~90% sudden loading）
Protection function: Output overcurrent protection, output overvoltage protection, output compensation reversal protection, output overcompensation protection, power unit overheating protection, output short circuit protection
Communication interface: RS485（Standard）、RS232(Optional）、Ethernet port (optional)
External analog interface: Support emergency stop, start/stop, fault detection, operation status detection interface; 0-5V/4-20mA analog signal input control (optional)
Safety feature
Insulation resistance: ≥20mΩ
Voltage resistance: 2000VDC test 60S, no flying arcs, breakdown
Ground resistance: ≤100mΩ
Noise: ≤75dB
Protection grade: IP20
Cooling mode: Forced air cooling
Working environment
Ambient temperature: 0℃～40℃
Ambient humidity: 10%~90%(no condensation)
Altitude: ≤2000m
Size (W*H*D) mm: 1350x2100x800mm
